1000V AC/DC Multimeter
Product Description
The IDEAL® Digital Multimeter (model 61-347) is designed with reliability and accuracy in mind. Rated CAT IV 600V and CAT III 1000V, this auto-ranging, TRMS multimeter measures up to 10 Amps AC and DC current through test leads in series with the load. It handles up to 1000V AC/DC, AC voltage, frequency, resistance up to 60MΩ, continuity, capacitance, and diodes, and includes a K-Type thermocouple for temperature readings in both Fahrenheit and Celsius. The non-contact voltage sensor detects voltage between 40V and 600V, ensuring safety during use. The backlit display enhances visibility, while the illuminated red LED and audible tones alert you to voltage above 30 volts, continuity, and NCV detection. For convenience, the rubber boot features two probe storage points and built-in holders, allowing for easy, one-handed operation. The hang strap mount lets you suspend the meter from various surfaces (Universal Magnetic Hanging Strap model UMHS-757 sold separately), while industrial-grade over-moulding provides enhanced grip and 2 m drop protection. Additional features include HOLD, MIN/MAX, Relative, Range, and selectable Auto Power Off functions. The meter comes with three 1.5V AAA batteries and a fully accessible storage pouch with a belt loop, perfect for storing the meter, probes, and thermocouple. The IDEAL® 61-357 Multimeter offers dependable performance for a wide range of applications.
- UL Certified CAT IV 600V CAT III 1000V AC/DC 10A AC/DC TRMS Auto Ranging Digital Multimeter
- Provides True RMS AC voltage and current for accurate measurements on non-linear signals
- Measures AC/DC current, AC/DC voltage, frequency, resistance, continuity, capacitance, diodes, temperature and senses AC voltage
- LEAD position warning and open FUSE indication
- Built-in probe tip holders and hanging strap clip allows safer, easier measurement (Universal Magnetic Hanging Strap model UMHS-757 sold separately)
- Large easy to read backlit display, allows for safer/faster work in poorly lit environments
- Industrial grade boot enhances grip, allows meter to withstand a 6.6 foot (2 m) drop
- Includes soft case, test leads, batteries, and K-Type Thermocouple
| Quantity | 1 EA |
| AC Current (Amps) | 10A |
| AC Microamps | 6000 |
| AC Milliamps | 6000 |
| AC Millivolts | 6000 |
| AC Voltage (Volts) | 1000V |
| Capacitance Test | 6000µF |
| Frequency / Duty Cycle | 10Hz - 9.99KHz |
| High Voltage Alarm | ACV/DCV >30V |
| LCD Display Count | 6000 |
| NCV | Yes |
| Ohms | 60MΩ |
| Temperature Measurement Range (C) | -40°C - 1000°C |
| Temperature Measurement Range (F) | -40°F - 1832°F |
| UL Listing | cULus |
| Warranty | Limited 2 Year |
| Auto Power Off Disableable | Yes |
| Bar Graph | Yes |
| Magnetic Strap Mount | Yes |
| Range Hold | Yes |
| RCM Listing | Yes |
| Built-In Probe Holder | Yes |
| CE Listing | Yes |
| DC Current (Amps) | 10A |
| DC Microamps | 6000 |
| DC Milliamps | 6000 |
| DC Voltage (Volts) | 1000V |
| Fuse Notification | Yes |
| DC Millivolts | 6000 |
| Lead Warning | Yes |
| CAT Rating | CAT IV 600 V / CAT III 1000 V |
| Backlit Display | Yes |
| Batteries Included | Yes |
| Battery Chemistry | Alkaline |
| Colour | Black, Yellow |
| Returnable Indicator | Yes |
| RoHS Compliant | Yes |
| VOC Content | No |
| Audible Continuity | Yes |
| Auto Power Off | Yes |
| Auto Ranging | Yes |
| Data Hold | Yes |
| Diode Test | Yes |
| Low battery Indication | Yes |
| True RMS | No |
| Visual Continuity | No |
